V-PRO車輛翻滾系統
Features & Benefits
- Early warning of LTV rollover risk
- Visual and audible crew alerts
- Intercom cues in development
- Simple 2-box solution
- SPU – Sensor Predictor Unit Remote mount
- DAU – Display Annunciator Unit Dashboard mount
- NVG compatible display with dimmer control
- Flight-critical aviation heritage
- MIL-STD 810 compliant
- Strict software development processes
- Single supply voltage (24 V nominal)
- MIL-STD 38999 filtered connector
- Preloaded software for multiple LTV variants
- LVT variant selected by cable strapping
- Suitable for factory and after-factory installations
- Fully exportable outside US
|
|
|
V-PRO Three Steps to Rollover Mitigation
- Continuously measure vehicle dynamics
- Compute rollover risk 100 times a second
- Send rollover risk cues to all LTV crew
|
|
|
Specifications
| Parameter |
Unit |
Value |
Comments |
| Supply Voltage |
V |
16 / 24 / 36 |
Minimum / Nominal / Maximum |
| Total Power |
W |
4.0 |
DAU power supplied by SPU |
| Predictive Lead Time |
ms |
500 |
Without CAN bus access |
| Size |
inches |
4.25 x 5.25 x 3
3.4 x 2.8 |
SPU width x depth x height
DAU diameter x depth |
| Weight |
lbs |
2.1 / 0.9 / 3.0 |
SPU / DAU / Total |
| Operational Temperature |
°C |
-40 to +70 |
Audible alarm derated beyond – 20°C and 60°C |
| Storage Temperature |
°C |
-55 to +125 |
|
| Rollover Risk Visual Cues |
% |
Green / Yellow / Red |
< 50 / 50 to 70 / 80 to 100 |
|
|
|
|
|
|
|
|
|
 |
|
|
