On / Off and Safety Switches
The Fredericks Company manufacturers programmable ON/OFF switches for users requiring an output that switches at a specific angle trip point. These all-electronic switches contain no moving parts to wear out and can be easily configured to switch at wide range of trip angles at our factory or your facility.
Applications include:
- Tip-Over Switches
- Tip-Over Protection
- Crane Safety
- Position Switch
- Lift Platforms
Dual Axis Programmable Tilt Switch
Part Number 0729-1736-99
|
» |
Ideal for use in high lift safety applications |
|
» |
1 to 10 Degree Sensing Range |
|
» |
Fast Installation via Infrared Light Source Programming |
|
» |
Factory Programmed Trip Points, Damping and Delays |
|
» |
OEM Reprogramming of Trip Point Angles |
|
» |
Auto Zero on Power-up Option, Eliminating need for Mechanical Zeroing |
|
» |
Hermetic Sealing from Moisture and Dirt for Years of Continuous Operation |
|
|
|
Single Axis Programmable Tilt Switch
Part Number 0729-1727-99
|
» |
+4.5 to +28 Volt Single Power Supply |
|
» |
± 45 Degree Sensing Range |
|
» |
Unidirectional and Bi-directional Open Collector Outputs |
|
|
|
|
|
|
|
|
|
|
 |
|
|
