The 0737-1203-99 “THIN FLIM” sensor is designed for applications requiring highly repeatable mid-range angle measurement and a linear output. Long-term stability over its angle and temperature range is a distinctive characteristic of this sensor. The 0737-1203-99 uses patented “Thin Film” technology and construction to provide an accurate and robust angle sensor at an attractive price with excellent sensor-to-sensor repeatability and reliability. Unparalleled performance and features compared to any other commercially available product.

Specifications

Operating Range	±0.25°
Null Repeatability	≤ 0.5 arc seconds
Resolution	≤ 0.1 arc second
Symmetry (typ.)	≤ 20 %
Operating Temperature	-20°C to +100°C
Storage Temperature	-50°C to +125°C

Applications
»	Construction Laser Instruments and Transits
»	日光追蹤 and Satellite positioning
»	Geophysical and Structural Monitoring
»	Machine Tool/ Platform Leveling
»	Machine tool leveling
»	Medical positioning and monitoring
»	Medical Positioning and Monitoring
